We have a selection of Product Brochures and Information for Your Reference, as well as Articles for help and advice on keeping your pond healthy and clean. If you have any questions don’t hesitate to inquire with our friendly staff. Even if you have a plan already in mind and are not sure where to start, we are here to help bring your plans to fruition.

If you are just looking for some inspiration for a water garden, you can visit our Project Gallery, where we have images containing customer projects.

  • Product Brochures – These can be Printed to Help You With Product Selection or Provide Further Information.



CALCULATING THE VOLUME OF A POND:

Square or Rectangle Pond

Length x Width x Depth (all in metres) x 1000 = Litres

Eg: 2.4m x 1.2m x 0.45m = 1.296 x 1000 = 1296 litres

Round Pond

Pi (3.141) x D2 x H x .25

For shaped ponds use the average length x width x depth then reduce the total by 20-30% to allow for curves and varying depths. Better to over estimate volume.



PIPE SIZING / FLOW RATES:

The longer the tube length the larger the diameter required. If tubing needs to run more than three or four meters from pump to outlet, use the next size up to reduce friction loss.

13mm – maximum flow rate up to 1000 L/H

19mm – maximum flow rate up to 2000 L/H

25mm – maximum flow rate up to 3000 L/H

32mm – maximum flow rate up to 5000 L/H

40mm – maximum flow rate up to 8000 L/H

50mm – maximum flow rates over 8000 L/H
